2.8" HD TFT LCD Display
Adopt 2.8’’ HD TFT LCD display for a good Visibility.









Innovative Auto-protecting Technology
This feature ensures the radio work normally, when the loader is not matching (abnormal SWR and mismatch current, etc).










Built-in Bluetooth(Optional)
Equipped Bluetooth inside supports the further features such as BT accessories, BT wireless programming and other applications










Built-in Noise Reduction Function(Optional)
Featured with advanced noise reduction, supports extra 25 dB noise cancellation performance.








Full- duplex calling (Optional)
Full duplex calls allow for natural and intuitive communications without to push-to-talk(only in trunking mode).









Built –in GPS (Optional

Supports viewing of GPS position information and sending of GPS text message.









DMR Tier III Support
Supports DMR Tier III, just by software upgrade and make the radio application more rich and more advanced.









Rich API Support
Rich API supports the user or the third party to develop supplemental applications.









IP54 and MIL-STD-810 Standards Compliance
EM8100 is in accordance with the MIL-STD-810 and IP54(IEC60529) high reliability standards,
ensuring outstanding performance even in harsh environment.(The control panel meets the IP67 standards)










Remote Mount Control Head

The remote mount control head can be mounted on the dashboard without the radio chassis while the space is limited in motorcycle and vehicle.

General

  Frequency

   VHF1:136-174 MHz  UHF1:400-470MHz  UHF3:350-400MHz

  Channel Capacity

   1024

  Channel Space

   12.5KHz/25KHz

  Dimensions(H*W*D)

   60*174*190mm

  Weight

   1500g

  LCD

2.8” HD TFT LCD 240×320 pixels, 262K colors

  Operating Voltage

   DC13.6V±15%

  Current Drain


   <12A (45W)

   <8A (25W)

   <5A (5W)

Reliability

  Operating Temperature

   -30 - +60℃

  Storage Temperature

   -40 - +85℃

  IP rating/humidity

   IP54(The Control Panel IP67 Design)

  Shock& Vibration

   Per MIL-STD-810 C/D/E/F/G standard

  ESD

   IEC 61000-4-2(level 4) ±8KV(Contact)  ±15KV(Air)

Receiver

  Digital Sensitivity

   -120dBm/BER 5% / -116dBm/BER 1%

  Digital Dynamic Faded Sensitivity
   (100KM/H& 8KM/H Rayleigh Fading)

   -104dBm

  Analog Sensitivity

   -120dBm/12dB SINAD

  Intermodulation

   75dB (TIA603) /70dB(ETSI)

  Blocking

   95dB (TIA603 & ETSI)

  Spurious Response Rejection

   75dB (TIA603 & ETSI)

  Selectivity

   75dB@25 KHz(TIA603&ETSI) / 65dB@12.5KHz(TIA603&ETSI)

  Conducted Spurious Emission

   -57dBm

Rated Audio Power Output

4W(Internal@20ohm load)  / 7.5W(External@8ohm load)

Max Audio Power Output

8W(Internal@20ohm load)  / 20W(External@8ohm load)

  Rated Audio Distortion

   3%

  Hum and Noise

   45dB @25KHz /40dB@12.5KHz

  Audio Response

   +1dB - -3dB

  Digital Vocoder Type

   AMBE++/NVOC

  Digital Protocal

   ETSI-TS102 361-1, -2,-3,-4

Transmitter

  Frequency Stability

   0.5ppm

  RF Power Output

   High Power Model:45-50W  Low Power Model:25W

  Digital Modulation

   7K60FXD(Data Only)  /7K60FXW(Data and Voice)

  FM Modulation

   16K¢F3E@25KHz  /11K¢F3E@12.5KHz

  4FSK Modulation Accuracy

   5%

  4FSK BER

   0%

  4FSK and Magnitude Error

   5%/1%

  Adjacent Channel Power

   70dB@25KHz /60dB@12.5KHz

  Conducted and Radiated Emission

   -36dBm <1GHz /-30dBm >1GHz

  Transmission Deviation limits

   5KHz@25KHz /2.5KHz@12.5KHz

  Audio Distortion

   3%

  Hum & Noise

   45dB@25KHz /40dB@12.5KHz

  Audio Response

   +1dB~-3dB

GPS&GLONASS

  TIFF Cold Start

   60s

  TIFF Hot Start

   10s

  Horizontal Accuracy

   10meters

Funciones


EM8100
* Full Duplex Communications
* 2.8” HD TFT LCD Display
* IP54 and MIL-STD-810 Standards Compliance
* DMR Tier II Conventional and DMR Tier III Trunked
